Model 77XLP
£6,995.00 ex VAT / £8,394.00 inc VAT
All prices exclude delivery.
Please contact us for a delivery cost to your location
Please select a model from the below drop-down
list for any Price differences specific to your Spreader model.
Please contact us for more details or to order
- 2.63m3 (3.44 cu yds) heaped capacity (that’s typically up to around 2.0 ton fully laden with well rotted wet manure)
- Dual horizontal rear beaters for maximum shredding action
- Just like the ’57’ and ’77’, the 77XL is ideal for restricted space applications, and with the advantage of PTO control, can often be found working inside glasshouses and polytunnels!
Exactly the same body length and width as the Model 77, the Model 77XL has taller ‘greedy board’ side extensions (increasing capacity by 29%) and the addition of an upper beater.
The dual rear beaters will handle and shred heavy matted strawy manures with ease.
Only a 24hp (min) tractor is required to operate the Model 77XL
Specs
Type
- PTO driven, dual horizontal beater, rear discharge
Rated Capacity (ASAE S324.1 standard method)
- Heaped 2.63m3 (93cuft)
- Level 1.69m3 (59cuft)
Body Dimensions
- L=2.89m (9’6″)
- W=0.94m (3’1″) + body flare
- H=0.66m (2’2″)
Overall Dimensions
- L=4.11m (13’6″)
- W=1.57m (5’2″)
- H=1.09m (3’7″)
Wheels, Tyres & Track
- 7.6″ x 15″ Ribbed pattern tyres on 4 bolt steel wheels
- 1.33m (4’4″) track width (centrline tyre to centreline tyre)
Approx Unladen Weight (standard spec.)
- 410Kg (902lbs)
Construction
- All steel MIG welded construction body
- Oven baked powder coat finish
- 20mm high density re-cycled plastic non-rotting floor
- 9mm T-rod Apron Chains
- PTO Gearbox and #RC50 Roller Chain for Beater and Apron Drive
- Sealed Bearings
- Folding jack stand as standard
